Data Science Toolbox: How to use Julia with Tableau

R allows Tableau to execute Julia code on the fly
R allows Tableau to execute Julia code on the fly

Michael, a data scientist, who is working for a German railway and logistics company, recently told me during an FATUG Meetup that he loves Tableau’s R and Pyhton integration. As he continued, he raised the raised the question for using functions they have written in Julia. Julia, a high-level dynamic programming language for high-performance numerical analysis, is an integral part of newly developed data strategy in the Michael’s organization.

Tableau, however, does not come with native support for Julia. I didn’t want to keep Michael’s team down and was looking for an alternative way to integrate Julia with Tableau.

This solution is working flawless in a production environment since several months. In this tutorial I’m going to walk you through the installation and connecting Tableau with R and Julia. I will also give you an example of calling a Julia statement from Tableau to calculate the sphere volume.

1. Install Julia and add PATH variable

You can download Julia from julialang.org. Add Julia’s installation path to the PATH environment variable.

2. Install R, XRJulia and RServe

You can download base R from r-project.org. Next, invoke R from the terminal to install the XRJulia and the RServe packages:

> install.packages("XRJulia")
> install.packages("Rserve")

XRJulia provides an interface from R to Julia. RServe is a TCP/IP server which allows Tableau to use facilities of R.

3. Load libraries and start RServe

After packages are successfully installed, we load them and run RServe:

> library(XRJulia)
> library(Rserve)
> Rserve()

Make sure to repeat this step everytime you restart your R session.

4. Connecting Tableau to RServe

Now let’s open the Help menu in Tableau Desktop and choose Settings and Performance >Manage External Service connection to open the External Service Connection dialog box:

TC17 External Service Connection

Enter a server name using a domain or an IP address and specify a port. Port 6311 is the default port used by Rserve. Take a look on my R tutorial to learn more about Tableau’s R integration.

5. Adding Julia code to a Calculated Field

You can invoke Calculated Field functions called SCRIPT_STR, SCRIPT_REAL, SCRIPT_BOOL, and SCRIPT_INT to embed your Julia code in Tableau, such as this simple snippet that calculates sphere volume:

6. Use Calculated Field in Tableau

You can now use your Julia calculation as an alternate Calculated Field in your Tableau worksheet:

Using Julia within calculations in Tableau (click to enlarge)
Using Julia calculations within Tableau (click to enlarge)

Feel free to download the Tableau Packaged Workbook (twbx) here.

Further reading: Mastering Julia

Social Media and the Customer-centric Data Strategy #data17 #resources

Social media marketing mix
Do you analyze your social media marketing mix? | Photo Credit: via Richard Goodwin

With over 3 billion active social media users, establishing an active presence on social media networks is becoming increasingly essential in getting your business front of your ideal audience. These days, more and more consumers are looking to engage, connect and communicate with their favorite brands on social media.

Adding social media to your customer-centric data strategy will help boost brand awareness, increase followership, drive traffic to your website and generate leads for your sales funnel. In 2017, no organization should be without a plan that actively places their brand on social media, and analyzes their social media data.

Once you’ve started diving into social media analytics, how do you bring it to the next level? This session covers a customer-centric data strategy for scaling a social media data program.

Here are the links (i.e. additional resources) featured during the session to help you formulate your social media data program in order to build a stronger presence and retrieve powerful insights:

The Data Opportunity

TC17 Social Media Slides: The Data Opportunity

Focus on relevant metrics for your strategy

TC17 Social Media Slides: Sentiment Analysis

How to get Social Media in Tableau?

TC17 Social Media Slides: 3rd Party Platform Talkwalker

Tips to Level Up

TC17 Social Media Slides: Unshorten URLs in Tableau with R

Tutorials and Slide Set

The slides and tutorials presented at Tableau Conference on Tour in Berlin are also available on SlideShare, and on YouTube in English and German.

English Tutorials

German Tutorials

Slide Set

It’s My 10 Year Blogging Anniversary!

Photo from an early blog post: 2007 Hampi, a temple town in South India recognised as UNESCO World Heritage Site
Photo from an early blog post: 2007 Hampi, a temple town in South India recognized as UNESCO World Heritage Site (Flickr)

Woohoo, it’s already ten years since I started this blog. Can’t believe it! Thanks to all of those who read my posts, and who encouraged and inspired me. Without you blogging would be only half the fun! Now, let’s have a little recap…

2007-2009 SAP and India:

It all started in 2007. I was studying Computer Science, and decided to go for an internship abroad. China and India were on my short list. I decided for India, applied for a scholarship and asked some companies for interesting project work. Before starting the adventure, I published my very first blog post to keep family and friends in loop.

For the next seven month, I lived in Bangalore, and worked for SAP Labs India to develop prototypes for mobile BI apps. I spent plenty of weekends to explore India and surrounding countries. After returning from India, I continued to work for SAP at their headquarters while finishing my degree in Karlsruhe.

2009-2012 CERN:

CERN, surrounded by snow-capped mountains and Lake Geneva, grabbed my attention during the end of my studies. CERN has tons of data: some petabytes! Challange accepted. CERN is known for its particle accelerator Large Hadron Collider (LHC). We applied machine learning to identify new correlations between variables (LHC data and external data) that were not previously connected.

2012-2015 Capgemini and MBA:

Back in Germany, I wanted to bring Big Data Analytics to companies. To one company? No, to many companies! So instead of getting hired as Head of BI for an SME, I started to work for Capgemini. I had fantastic projects, designed data-driven usecases for the financial sector, and gave advice for digital transformation inititives.

In order to keep in balance with all the project work, I dedicated many of my weekend for studies and got enrolled in Frankfurt School’s Executive MBA programme. During my studies, I focused on Emerging Markets and visited a module at CEIBS in Shanghai.

2015-201? Tableau and Futura:

I knew Tableau from my time as consultant. It is an awesome company with a great product and a mission: help people see and understand their data. That’s me! I joined Tableau to help organizations through the transition from classic BI factories to modern self-service analytics by developing data strategies, so that data can be treated as a corporate asset. This includes education, evangelism and establishing a data-driven culture.

In the evenings I’m working for Futura Analytics, a fintech startup, which I co-founded in 2017. Futura Analytics offers real-time information discovery, and transforms data from social media and other public sources into actionable signals.

What’s next?

Currently I’m looking forward to give my Data Strategy talk on TC17 accompanied by a TensorFlow demo scenario. I’m also learning Mandarin, the predominant language of business, politics, and media in China and Taiwan, for quite a while. Let’s see if that is going to influence my next steps… 🙂

Monkey Business: Always be Ready to Demo

The famous Tableau Superstore demo data set
The famous Tableau Superstore demo data set

Usually, I really don’t like looking on the screens of other passengers. On this early morning train from Frankfurt to Cologne, however, the screen of my seatmate caught my attention. Where have I seen the logo on his slide deck before? Two coffee sips later, it came to me: it was the logo of Monkey 47, a very delicious gin, distilled in the heart of the Black Forest. So I asked my neighbor: “Is that the Monkey 47 logo?”

He was happy that I recognized his brand and we had a small chat about gin and the Black Forest. Turns out his name is Thomas, and he is the head of Sales and Marketing for Monkey 47. Thomas mentioned that his team is planning a tour to promote Monkey 47 in a number of cities. That sounds similar to what we are doing with the Tableau Cinema Tour, so I showed him our Cinema Tour landing page and explained briefly who we are and what our mission is.

I asked him how he is organizing his data. Thomas revealed that he lives in Excel hell: “spreadsheets with thousands of rows and way too many columns”. This also sounded familiar. I opened up our Superstore.xlsx in Excel and asked: “Do your Excel sheets look like this?” Thomas replied: “Yes!”

Here we go! I drag’n’dropped the file on my Tableau desktop icon and paced through a 7-minute-demo ending with an interactive dashboard. Thomas was flabbergasted. To polish things off, I showed him the interactive Twitter Sentiment Dashboard embedded in my blog. Thomas grabbed his jacket and gave me a business card, saying: “We need Tableau!”

Monkey 47 business card (back side)
Monkey 47 business card (back side)

This story was originally written for Tableau’s EMEA Sales Newsletter. I think it’s a good read for the holidays, and wish you all Merry Christmas!

TabPy Tutorial: Integrating Python with Tableau for Advanced Analytics

TabPy allows Tableau to execute Python code on the fly
TabPy allows Tableau to execute Python code on the fly

In 2013 Tableau introduced the R Integration, the ability to call R scripts in calculated fields. This opened up possibilities such as K-means clustering, Random Forest models and sentiment analysis. With the release of Tableau 10.2, we can enjoy a new, fancy addition to this feature: the Python Integration through TabPy, the Tableau Python Server.

Python is a widely used general-purpose programming language, popular among academia and industry alike. It provides a wide variety of statistical and machine learning techniques, and is highly extensible. Together, Python and Tableau is the data science dream team to cover any organization’s data analysis needs.

In this tutorial I’m going to walk you through the installation and connecting Tableau with TabPy. I will also give you an example of calling a Python function from Tableau to calculate correlation coefficients for a trellis chart.

1. Install and start Python and TabPy

Start by clicking on the Clone or download button in the upper right corner of the TabPy repository page, downloading the zip file and extracting it.

TabPy download via GitHub web page

Protip: If you are familar with Git, you can download TabPy directly from the repository:

> git clone git://github.com/tableau/TabPy

TabPy download via Git command line interface

Within the TabPy directory, execute setup.sh (or setup.bat if you are on Windows). This script downloads and installs Python, TabPy and all necessary dependencies. After completion, TabPy is starting up and listens on port 9004.

2. Connecting Tableau to TabPy

In Tableau 10.2, a connection to TabPy can be added in Help > Settings and Performance > Manage External Service Connection:

Tableau main menu
Tableau main menu

Set port to 9004:

External Service Connection dialogue
External Service Connection dialogue

3. Adding Python code to a Calculated Field

You can invoke Calculated Field functions called SCRIPT_STR, SCRIPT_REAL, SCRIPT_BOOL, and SCRIPT_INT to embed your Python script in Tableau:

Python script within Tableau
Python script within Tableau

4. Use Calculated Field in Tableau

Now you can use your Python calculation as Calculated Field in your Tableau worksheet:

Tableau workbook featuring a Python calculation
Tableau workbook featuring a Python calculation

Feel free to download the Tableau Packaged Workbook (twbx) here.

[Update 3 Jan 2017]: Translated to Japanese by Tomohiro Iwahashi: Tableau + Python 連携 (Tabpy) を使ってみよう!

[Update 30 Mar 2017]: A German translation of this post is published on the official Tableau blog: TabPy Tutorial: Integration von Python mit Tableau für Advanced Analytics
